LameMusic

A sequencer for LameAudio that allows your games to play music.

music : "LameMusic"

About

Call music.Start once at the beginning of your program to start the music engine.

Info

LameAudio must be started before LameMusic.

To load a song, call music.Load using the Addr function of the song object as an argument. Only one song can play at a time. Loading a new song will stop any currently playing one.

music.Load(mycoolsong.Addr)

You can use music.Play to play a song once, or music.Loop to play it forever. Call music.IsPlaying to find out if a song is currently playing.

Once you're tired of listening to music, call music.Stop to end the song. Playing the song again will start over from the beginning.

Song Format

LameStation songs consist of two main sections: pattern and sequence data.

Pattern Data

Patterns contain melodies, riffs, harmonies and any musical parts that fit in a measure.

  • Notes per measure (first byte) (0-255) - Each pattern must have exactly this many notes.

  • Note (0-127) - Play note n between 0 and 127.

  • Stop note ($83) - Stop playing note.

  • Do nothing ($82) - Do nothing (continue playing or not playing current note).

DAT

pattern_data
byte    4

byte    42,  44,  46,  49
byte    42, $82, $82, $83

Sequence Data

The sequence defines how the patterns are arranged in time and across channels. There should be one command, as many times as you want.

  • Pattern (<ch1>, <ch2>, <ch3>, <ch4>) - Set next pattern to pattern 1-127 for all four channels. Pattern 0 plays nothing.

  • End song ($80) - End the song.

  • ADSRW ($A0, <a>, <d>, <s>, <r>, <w>) - Change the sound of channel(s).

  • Tempo ($B0, 0-255) - Change the tempo of the song.

  • Transpose ($C0, -128-127) - Transpose the channel up or down number of notes.

DAT

sequence_data
byte    1, 0, 0, 0
byte    $80

Song Interface

For LameMusic to access the song object, some extra code is needed. This code provides an address which LameMusic reads to figure out where the song data is.

DAT
    song_data
    word    @pattern_data, @sequence_data
PUB Addr
    result.word[1] := @@0
    result.word{0} := @song_data

Functions

music.Start

Initialize the LameMusic library.

music.Start

Call music.Start once at the beginning of your program to start the music engine.

Info

LameAudio must be started before LameMusic.

music.IsPlaying

Check if a song is playing. Returns true if song is playing, otherwise false.

music.IsPlaying

music.Load

Load a song to play.

music.Load(songAddr)
  • songAddr - Addr of the song object to play.

To load a song, call music.Load using the Addr function of the song object as an argument. Only one song can play at a time. Loading a new song will stop any currently playing one.

music.Load(mycoolsong.Addr)

music.Loop

Play the loaded song forever.

music.Loop

music.Play

Play the loaded song once.

music.Play

music.Stop

Stop the loaded song, if playing.

music.Stop
